Horizontal Sync Complex
|
Illustrating "Front Porch," "Sync Tip," "Back Porch" with Color Burst
riding on it.
The interval between the end of the sync tip & the start of the
burst is sometimes refered to as the "Breeze -way." Note also, the "Burst
Flag" (D.C. Restore clamp). |
|
|
|
|
|
|
|
|
|
